Trapezoidal Sheet Roll Forming Machine

Trapezoidal Sheet Roll Forming Machine

33000-45000 USD ($)/Set

Product Details:

  • Computerized Yes
  • Automatic Grade Automatic
  • Control System PLC Control
  • Rolling Speed 20-25 m/m
  • Cutting System Hydraulic cutting
  • Cutting Thickness 0.3-0.8 Millimeter (mm)
  • Voltage 415 Volt (v)
  • Supply Ability : 20 Set Per Year
  • Click to view more
X

Price And Quantity

  • 33000-45000 USD ($)/Set
  • 1 Set
  • 33000.00 - 45000.00 USD ($)/Set

Product Specifications

  • PLC Control
  • Yes
  • Hydraulic cutting
  • Automatic
  • 0.3-0.8 Millimeter (mm)
  • 20-25 m/m
  • 12000 Kilograms (kg)
  • 415 Volt (v)
  • 12months
  • 11.5*1.6*1.6 Meter (m)

Trade Information

  • Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C)
  • 20 Set Per Year
  • 90 Days
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia

Product Description

We are an eminent manufacturer, exporter and supplier of supreme quality High Speed Trapezoidal Sheets Roll Forming Machine. At our advanced manufacturing unit, the offered machine is manufactured with the use of paramount quality components and cutting-edge technology in tune with the international quality standards. Finding its applications in metal fabrication industry for forming metal sheets in trapezoidal shape, this machine is tested on certain parameters of quality before its delivery at the clients' end. Apart from this, our esteemed clients can easily purchase this High Speed Trapezoidal Sheets Roll Forming Machine at most economic prices from us.


Features:

  • Long service life
  • Robust construction
  • Non-interrupted performance
  • Low maintenance

Trapezoidal Sheet Roll Forming Machine:

Detailed Product Description :

Machine's Size:

9500X1800X1500mm (LxWxH)

Main Power:

7.5KW

Cutting Style:

Automatic Cutting

Roller Material:

No.45 Steel, Plated With Chrome

Cutter Material:

Cr12 Mould Steel

Controlling System:

Mitsubishi PLC, Screen

Shaft For Roller:

72mm Dia. Solid Steel

Guarantee:

One Year Guarantee Time, Lifetime Service

Quality System:

ISO 9001

Forming Speed:

About 20m/min.


380V Trapezoidal Color Roofing Sheet Roll Forming Machine High Frequency with ISO

Technical data of Trapezoidal sheets roll forming machine :


Suitable material

Q235 color steel sheet;0.3-0.7mm, 1000&1250mm coil width

Forming speed

about 20m/min

Power Requirement

Main motor power: 7.5 Kw(Depend on final design)

Hydraulic station power: 2.2Kw(Depend on final design)

Material of forming rollers

No.45 steel, plated with chrome on surface.

Material of cutter

Cr12 mould steel with quench treatment, HRC58-60

Material of shaft

High quality 45# steel with heat treatment. Roller grinder milling.

Shaft diameter

72mm

Controlling system

Mitsubishi PLC & converter

Total weight of machine

About 8500KGS

Machines size

about 15m,1.8m 1.5m (Depend on final design)

Shipping

1x40GP container can load one machine




HANGZHOU ZHONGYUAN MACHINERY FACTORY
